Shielded junction box | 53 mm | installation box for drywall and flush-mounted installation | halogen free

 29,42 ( 29,42 excl. VAT)

Shielded junction boxes for reducing low-frequency alternating electrical fields. This high-quality connection box with a depth of 53 mm is ideally suited for both drywall and concealed installation.

PROnatur24® SHOP
Independently verified
4.67 store rating (44 reviews) | 4.72 product rating

Shielded junction box with a depth of 53 mm. Junction box, halogen-free, for the installation of shielded electrical cables in drywall and concealed. For shielded rooms according to Faraday to reduce electrical fields LF.

This shielded installation box is used to reduce low-frequency alternating electrical fields. This is an ideal addition to the wall, which is shielded by means of shielding paint, in order to close the “hole socket” in the Farraday cage as well as possible.

Shielded with metal vacuum coating. Potential connection cable 1,5 mm² rigid. As a connection box for plaster and cavity wall. 107 x 107 x 53 mm. Standard mounting distances.

Shielded junction box | 53 mm | installation box for drywall and flush-mounted installation | halogen free
Installation work

General information about the shielded junction box, 53 mm deep

The coating on the junction box is electrically conductive and therefore perfectly suited for the effective limitation of alternating electrical fields. The focus of this shielded installation box is in use in bedrooms, hospitals, computer rooms and other sensitive areas to limit alternating electrical fields.

  • Special conductive metal vacuum coating for shielding against electrical alternating fields (in accordance with the EU’s 2002/95/EG guidelines)
  • Approved screw spacing
  • Connecting wire 1,5 mm² (Copper, massive, rigid, transparent insulation), quick installation in
  • Plug terminals (push-wire connectors)
  • Installation of the insertions with screws and stretches
  • Standard screw spacing of 60mm

Circuit diagram shielded junction box

Circuit diagram shielded wall box

Details on the shielded cavity wall socket, 53 mm deep

  • Can be used for a plate with a thickness of 7 to 35 mm
  • several breakout openings for cable entries
  • making an opening in the wall with four 35mm drilled holes (drilling template)
  • including cover screws and shielded caps (with further potential connection)
  • plastic (halogen-free PP)
  • Temperature range during processing -5° C to max. + 70° C (material breaks at too low temperatures)
Made in Germany
Weight 0,05 kg
Dimensions 6,7 × 6,7 × 4,7 cm
Scope of delivery

Cavity-wall box

Brand

Country of origin

Germany
